| 48MP Sony IMX858 M12 Auto Focus USB 2.0 Camera Module |
| Model No. YDS-USB-IA2550M V1.0 |
| Camera Module No. |
YDS-USB-IA2550M V1.0 |
| Resolution |
48MP |
| Image Sensor |
IMX858 |
| Sensor Type |
1/3.2" |
| Pixel Size |
0.7 um x 0.7 um |
| EFL |
12.00 mm |
| F.NO |
2.0 |
| Pixel |
8000 x 6000 |
| View Angle |
36.0°(DFOV) 26.0°(HFOV) 20.5°(VFOV) |
| Lens Dimensions |
20.00 x 20.00 x 28.00 mm |
| Module Type |
Auto Focus |
| Interface |
USB 2.0 |
| Output Format |
MJPG |
| Auto Control |
Saturation, Contrast, Acutance
White Balance, Exposure |
| Audio |
Digital Microphone, Single, Dual Channel |
| Input Voltage |
DC 5V |
| Working Current |
Max 500mA |
| PCB Size |
64.0 x 38.0 x 32.5 mm |
| System Compatibility |
Windows XP (SP2, SP3), Vista, 7, 8, 10, 11
Android, Mac OS, Linux or OS with UVC Driver
Raspberry Pi by USB Port |
| Software for USB Camera |
AMCAP, Webcam Viewer, V4L2 Controls
Contacam, VLC Player, MotionEye OS
iSpy, ZoneMider, Yawcam |
| Lens Type |
650nm IR Cut |
| Operating Temperature |
-20°C to +85°C |
| USB Cable |
USB Cable |
|
